AMD Ryzen™ 5 9600X

Performance without compromise.

AMD Ryzen 9000 Series processor

Configure your small form factor PC with the AMD Ryzen™ 5 9600X processor. Perfect for compact, high-performance builds, this processor delivers exceptional power without compromising on your space-saving design.

AMD Ryzen 9000 Series processor

Supercharged for compact builds.

Breakthrough performance meets minimal footprint. Experience AMD's most advanced desktop processors, bringing next-gen gaming, content creation, AI development, and professional power to your compact build.

Corsair rear PSU view

Small size. Ryzen power.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X workstation PC.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X gaming PC.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X deep learning PC.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X rendering PC.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X video editing PC.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X streaming PC.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X content creation PC.

Design and configure your ideal SFF AMD Ryzen™ 5 9600X home server PC.

Configure your PC

AMD Ryzen™ 5 9600X Specifications

General Specifications
  • Name: AMD Ryzen™ 7 9700X
  • Family: Ryzen
  • Series: Ryzen 9000 Series
  • Form Factor: Desktops, Boxed Processor
  • Market Segment: Enthusiast Desktop
  • AMD PRO Technologies: No
  • Consumer Use: Yes
  • Regional Availability: Global
  • Former Codename: Granite Ridge AM5
  • Architecture: Zen 5
  • CPU Cores: 8
  • Multithreading (SMT): Yes
  • Threads: 16
  • Max Boost Clock: Up to 5.5 GHz
  • Base Clock: 3.8 GHz
  • L1 Cache: 640 KB
  • L2 Cache: 8 MB
  • L3 Cache: 32 MB
  • Default TDP: 65W
  • Processor Technology for CPU Cores: TSMC 4nm FinFET
  • Processor Technology for I/O Die: TSMC 6nm FinFET
  • Package Die Count: 2
  • Unlocked for Overclocking: Yes
  • AMD EXPO™ Memory Overclocking Technology: Yes
  • Precision Boost Overdrive: Yes
  • Curve Optimizer Voltage Offsets: Yes
  • AMD Ryzen™ Master Support: Yes
  • CPU Socket: AM5
  • Supporting Chipsets: A620, X670E, X670, B650E, B650, X870E, X870, B840, B850
  • CPU Boost Technology: Precision Boost 2
  • Instruction Set: x86-64
  • Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
  • Thermal Solution (PIB): Not Included
  • Recommended Cooler: Premium air cooler recommended for optimal performance
  • Max Operating Temperature (Tjmax): 95°C
  • Launch Date: 08/08/2024
  • OS Support: Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit
Connectivity
  • Native USB 3.2 Gen 2 (10Gbps) Ports: 4
  • Native USB 2.0 (480Mbps) Ports: 1
  • PCI Express Version: PCIe® 5.0
  • Native PCIe Lanes: {Total: 28, Usable: 24}
  • Additional Usable PCIe Lanes from Motherboard: {X870E: 8x Gen4, X870: 4x Gen4, X670E: 12x Gen4, X670: 12x Gen4, B650E: 8x Gen4, B650: 8x Gen4}
  • NVMe Support: Boot, RAID0, RAID1, RAID5, RAID10
  • System Memory Type: DDR5
  • Memory Channels: 2
  • Max Memory: 192 GB
  • System Memory Subtype: UDIMM
  • Max Memory Speed: {2x1R: DDR5-5600, 2x2R: DDR5-5600, 4x1R: DDR5-3600, 4x2R: DDR5-3600}
  • ECC Support: Yes (Requires mobo support)
Graphics Capabilities
  • Graphics Model: AMD Radeon™ Graphics
  • Graphics Core Count: 2
  • Graphics Frequency: 2200 MHz
  • USB Type-C DisplayPort Alternate Mode: Yes
Product IDs
  • Product ID Boxed: 100-100001404WOF
  • Product ID Tray: 100-000001404
Key Features
  • Supported Technologies: AMD EXPO™ Technology, AMD Ryzen™ Technologies
