AMD Ryzen™ 9 9950X
Performance without compromise.
Configure your small form factor PC with the AMD Ryzen™ 9 9950X processor. Perfect for compact, high-performance builds, this processor delivers exceptional power without compromising on your space-saving design.
Supercharged for compact builds.
Breakthrough performance meets minimal footprint. Experience AMD's most advanced desktop processors, bringing next-gen gaming, content creation, AI development, and professional power to your compact build.
Small size. Ryzen power.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X workstation PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X gaming PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X deep learning PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X rendering PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X video editing PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X streaming PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X content creation PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X home server PC.
Design and configure your ideal SFF AMD Ryzen™ 9 9950X workstation PC. gaming PC. deep learning PC. rendering PC. video editing PC. streaming PC. content creation PC. home server PC.
Configure your PCAMD Ryzen™ 9 9950X Specifications
- Name: AMD Ryzen™ 9 9950X
- Family: Ryzen
- Series: Ryzen 9000 Series
- Form Factor: Desktops, Boxed Processor
- Market Segment: Enthusiast Desktop
- AMD PRO Technologies: No
- Consumer Use: Yes
- Regional Availability: Global
- Former Codename: Granite Ridge AM5
- Architecture: Zen 5
- CPU Cores: 16
- Multithreading (SMT): Yes
- Threads: 32
- Max Boost Clock: Up to 5.7 GHz
- Base Clock: 4.3 GHz
- L1 Cache: 1280 KB
- L2 Cache: 16 MB
- L3 Cache: 64 MB
- Default TDP: 170W
- Processor Technology for CPU Cores: TSMC 4nm FinFET
- Processor Technology for I/O Die: TSMC 6nm FinFET
- Package Die Count: 3
- Unlocked for Overclocking: Yes
- AMD EXPO™ Memory Overclocking Technology: Yes
- Precision Boost Overdrive: Yes
- Curve Optimizer Voltage Offsets: Yes
- AMD Ryzen™ Master Support: Yes
- CPU Socket: AM5
- Supporting Chipsets: A620, X670E, X670, B650E, B650, X870E, X870, B840, B850
- CPU Boost Technology: Precision Boost 2
- Instruction Set: x86-64
- Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
- Thermal Solution (PIB): Not Included
- Recommended Cooler: Liquid cooler recommended for optimal performance
- Max Operating Temperature (Tjmax): 95°C
- Launch Date: 08/15/2024
- OS Support: Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit
- Native USB 3.2 Gen 2 (10Gbps) Ports: 4
- Native USB 2.0 (480Mbps) Ports: 1
- PCI Express Version: PCIe® 5.0
- Native PCIe Lanes: {Total: 28, Usable: 24}
- Additional Usable PCIe Lanes from Motherboard: {X870E: 8x Gen4, X870: 4x Gen4, X670E: 12x Gen4, X670: 12x Gen4, B650E: 8x Gen4, B650: 8x Gen4}
- NVMe Support: Boot, RAID0, RAID1, RAID5, RAID10
- System Memory Type: DDR5
- Memory Channels: 2
- Max Memory: 192 GB
- System Memory Subtype: UDIMM
- Max Memory Speed: {2x1R: DDR5-5600, 2x2R: DDR5-5600, 4x1R: DDR5-3600, 4x2R: DDR5-3600}
- ECC Support: Yes (Requires mobo support)
- Graphics Model: AMD Radeon™ Graphics
- Graphics Core Count: 2
- Graphics Frequency: 2200 MHz
- USB Type-C DisplayPort Alternate Mode: Yes
- Product ID Boxed: 100-100001277WOF
- Product ID Tray: 100-000001277
- Supported Technologies: AMD EXPO™ Technology, AMD Ryzen™ Technologies
